    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction

    Ask Lasest Price
    Model Number : RTN 910A
    Brand Name : Other
    Supply Ability : 1000 Carton/Cartons per Day
    Price : $1,269.00/sets 2-49 sets
    • Product Details
    • Company Profile

    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction

    PRODUCT DESCRIPTION
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    Split Type Long Range Microwave Transmission Equipment Assembly IDU RTN 910A
    The Huawei 6–42 GHz traditional frequency IP microwave has a maximum of 2 Gbit/s per carrier and 16 Gbit/s per antenna ultra-large transmission capacity, it is the industry’s first IP microwave that supports TDM/Hybrid/Packet/Routing services on the unified platform, satisfying the requirements of large-capacity IP service transmission and IP-based evolving of traditional PDH/SDH microwave. The solution provides a flexible architecture that can be deployed in split, full-outdoor, or full-indoor scenarios. It features high reliability and end-to-end unified O&M management. It is widely used in broadband wireless transmission in vertical sectors, such as government, broadcasting, oil & gas, education, and electric power.
    TECHNICAL SPECIFICATION
    Network layer
    Suitable for: access layer and aggregation layer
    Frequency band
    6 ~ 42 GHz
    Channel spacing
    3.5/ 7/14/28/40/56/112 MHz
    Bandwidth
    Determine based on ODU bandwidth
    Modulation mode
    QPSK Strong，QPSK，16QAM Strong，16QAM，32QAM， 64QAM，128QAM，
    256QAM，512QAM，512QAM Light， 1024QAM，1024QAM Light，2048QAM，
    4096QAM
    Maximum number of RFUs
    Based on the RTN910A technical specifications
    RF direction
    6
    Air port capacity
    Single carrier 1166~2500 Mbit/s (non XPIC)
    Exchange capacity
    90 Gbit/s (using CSHOF), 10 Gbit/s (using CSHO)
    TDM crossover capacity
    32×32 VC-4
    Link aggregation
    2-4
    Interface type
    E1，T1，STM-1（e/o），FE（e/o），GE（e/o）， 2.5GE（o） ，10GE（o）
    Transmit power @QPSK
    Based on the RTN910A technical specifications
    Super dual frequency
    Based on the RTN910A technical specifications
    L3 VPN
    Based on the RTN910A technical specifications
    eCPRI support
    Based on the RTN910A technical specifications
    Rf configuration mode
    N+0 N×（1+0） 1+1 N+1 XPIC 2 × 2 CA 4 ×4 MIMO
    Feature
    Ethernet II, IEEE 802.3 and IEEE 802.1q/p field addition/deletion, and VLAN label exchange (IEEE 802.1q/p) ISIS, OSPF, BGP, RSVP,
    LDP Support for flow control (IEEE 802.3x) Support Link Aggregation Group (IEEE 802.3ad LAG and L1 LAG) RMON (IETF RFC 2819)
    Business type
    Native ETH service: E-Line dedicated line service and E-LAN private network service PW based Native ETH services: E-Line dedicated
    line services, Ethernet aggregation services, E-LAN private network services (VPLS, representing virtual private network services)
    L3VPN, L2VPN (VLL), CES, MCE
    Key characteristics
    CES E1, IEEE 1588v2, USB start, H-QoS, PLA/EPLA/EPLA+, AES-256 encryption, device anti-theft, 1+1, N+1, XPIC, AM, TDM, PWE3/MPLS,
    SDB, L3VPN, CA, MIMO
    Antenna
    Parabolic antenna: 0.3m~3.7m
    IDU Weight
    5.4 kg（1+0） 6.2 kg（1+1）
    IDU Specification
    442 mm × 220 mm × 88 mm
    Environment
    Temperature: IDU -5 °C ~+60 °C ； ODU -33 °C ~ +55 °C Humidity: IDU 5%~95%； ODU 5%~100%
    Power source
    -38.4 V~-57.6 V
    Certificate
    CE、RCM、 FCC、IC、ETL、MCMC
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    COMPANY PROFILE
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    Why Choose Us
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    Exhibition
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    Certifications
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    Client Evaluation
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    Packing & Delivery
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    Long Range Microwave Link Rtn 910A 2*GE RJ45 4*10GE SFP 16*E1 12 Radio-Frequency Direction
    1. Who are we?
    We are based in Beijing, China, start from 2023,sell to Domestic Market(60.00%),North America(20.00%),South America(10.00%),Western Europe(10.00%). There are total about 11-50 people in our office.

    2. How can we guarantee quality?
    Always a pre-production sample before mass production;
    Always final Inspection before shipment;

    3. What can you buy from us?
    Microwave Equipment, Data Communication Equipment, Transmission Equipment, Storage Device, Server

    4. Why should you buy from us not from other suppliers?
    Microwave equipment:RTN910A/RTN905F/RTN950/RTN950A/RTN980/RTN980L/RTN320F/RTN380AX; Wavelength division equipment:OSN9800/OSN9600/ONS8800; OLT:MA5800X2/X7; Switch:S9310X/CE6881-48S6CQ-B/CE8851-32CQ8DQ-P/CE6863E-48S6CQ. OceanStor Dorado 6000 V6/2288H V6/5288V6

    5. What services can we provide?
    Accepted Delivery Terms: FOB,EXW；
    Accepted Payment Currency:USD,CNY;
    Accepted Payment Type: T/T;
    Language Spoken:English,Chinese
