ALL-IP: Uniform TDM/Hybrid/Packet platform, support Evolution
Smoothly
RTN980L can process all kinds of services separately or mixed in
the radio base on the most advanced uniform TDM/Hybrid/Packet
architecture, including E1/STM-1, native Ethernet, and PWE3/MPLS
E1/Ethernet, and so on. It not only meets the current requirements
of the longhaul microwave network, but also that of the evolution
to the pure packet longhaul microwave network in the future.
Agile: Most Flexible Design and support IF Combination
RTN980L has flexible design with full indoor, split mount and all
outdoor installation methods, and also support 2+0 or 3+0
lightweight BU, suit for the challenges from the different
deployment scenarios. RTN980 has unified platform for flexible
scheduling, and support multi-service access and mix pass, for
matching various scenarios.
High Capacity: Large bandwidth and high capacity
RTN980L provide high capacity with 16Gbps/32*STM-1 Ultra High
Capacity per Antenna. The throughput can reach up to 1Gbps/channel
in condition of 56M/1024QAM, by Bandwidth Accelerator technology.
For the common scenarios with large-granule Ethernet services in
the longhaul microwave network, RTN980L support aggregate up to 12
links to one logical linkto transmit large-granule service with the
advanced EPLA(Enhanced Physical Link Aggregation) technology, and
N+1 protection for the both TDM and Ethernet service, especially
the maximum number of N is up to 11, which is much stronger than
the traditional longhaul microwave equipments.
RTN980L already support 10GE air interface for large bandwidth
requirement in future.
